Mastech MS6300 Digital Multifunction Environmental Tester Anemometer
Introduction:
This meter is a digital Multifunction Environment Meters meter which combined the function of Sound Level, luminometer, Relative Humidity Meter, Temperature Meter and anemometer.
Specifications:
MS6300 environmental test chamber
Numerical Display: 4 digital Liquid Crystal Display.
Response Time: about 2 times/second
Features:
* display: LCD digital display;
* auto change range;
* data hold function;
* avg/max/min/dif(max-min)function;
* low battery voltage indication
* back light
* auto/manual power off selection;
* power supply: 6F22(9v)
General specification:
|
1. Numerical Display |
4 digital Liquid Crystal Display. |
|
2. Response Time |
about 2 times/second. |
|
3. Operating Environment |
-10°C~60°C(14°F~140°F) |
|
4. Storage Environment |
-10°C~50°C(14°F~122°F) |
|
5. Power Requirements |
Battery→ One 9V battery 006p or IEC 6F22 or NEDA1604 |
|
6. Low Battery Indication |
displayed |
|
7. Dimension |
Meter→ 280(L)x 89(W)x 50(H)mm; |
|
8. Weight |
Approx 430g |
Specification:
| Function | Range |
Resolution
|
Accuracy
|
|
Temperature
|
-10~60º C
14~140º F |
0.1º C
0.1º F |
± 1º C
± 2º F |
|
Humidity
|
20%~80%RH
< 20%or > 80%RH |
0.1%RH |
± 3.0%RH
± 5.0%RH |
|
Light
|
0~50000LUX
|
1LUX
|
± (5.0%+10)
|
| Anemo | 0.4~20m/s 1.4~72km/h 1.3~65.7ft/s 0.8~38.9knots |
0.1m/s
0.1km/h 0.1ft/s 0.1knots |
± (3.0%+10)
± (3.0%+10) ± (3.0%+10) ± (3.0%+10) |
|
Air Flow(CMM)
|
0~999900CMM | 0.1CMM(< 1000CMM) 1CMM(> 1000) |
± (3.0%+10)
|
|
Air Flow(CMM)
|
0~999900CMM |
0.1CFM(< 1000CFM)
1CFM(> 1000CFM) |
± (3.0%+10)
|
|
Sound Level
|
30~130dB(A) 35~130dB(C) |
0.1dB |
± 1.5dB
|
Brand: Graigar
Color: Black
Features:
- 1. Auto & Manual Ranging 2. Auto Power Off
- 3. Area range 0~999.9m², 0~999.9ft²
- 4.AVG / MAX / MIN / DIF (MAX-MIN)
- 5. A / C Weighting Indication 6. Data Hold
- 7.Display Backlight 8. Low Battery Display
model number: MS6300
Part Number: MS6300
